Gas Detector Tube
Gas Detector Tube
[Global Model]Muffle Furnace 300 x 440 x 390 220V
AS ONE Corporation
• Outer dimension (mm): 300 x 440 x 390
• Inner furnace dimension (mm): 120 x 225 x 110
• Capacity (L): 3
• Operating temperature range: 100? - 1150? (0.5? unit)
• Temperature distribution accuracy: +/- 3? at 1000?
• Temperature rise time: Approx 40 minutes, room temperature -> 1150?
• Control system: Program operation (50 patterns, 100 segments)
• Temperature sensor: K class thermocouple
• Heater capacity: 1.2kW
• Furnace body: Ceramic fiber
• Safety device: Overcurrent breaker, Excessive temperature rise setting device, Door opening and closing sensor, Key lock function, Exterior temperature sensitive type cooling fan, Microcomputer abnormality detection device (heater disconnection, Thermocouple disconnection, Memory content abnormality, Excessive temperature rise abnormality, Control substrate abnormality)
• External output: Recorder thermocouple output, Output for automatic gas introduction 1 - 2, Event contact output 1 - 4, Output for deodorizer, During-operation, end, alarm contact output, 3-color patolight output, SD card slot
• Exhaust port diameter: f23.5mm
• Weight: 22kg
• Power: AC220V
• Current capacity*: 12A (*All numerical data are representative values and are not guaranteed values. *Please prepare plenty of current capacity for power equipment. )
• Accessories: Furnace setter plate, Exhaust port plug, Exhaust sleep, AC cord (300-Plus is attached to the body)
• Option (sold separately): Deodorizer (ES71, ES72) Ventilator (VF71, VF72), Gas introduction unit (KDG-300, -1500, -3000, -5000), 3-color patolight, Different system excessive temperature rise sensor, Body fixing fitting unit, Electrical leakage breaker, Platinel thermocouple, wagon (KDW-100, KDW-200), Temperature sensor for recorder output
• *Vacuum gas replacement furnace type is also available. Please contact with us.
• Model number: 300Plus
• Country of origin: Japan
• Inner furnace dimension (mm): 120 x 225 x 110
• Capacity (L): 3
• Operating temperature range: 100? - 1150? (0.5? unit)
• Temperature distribution accuracy: +/- 3? at 1000?
• Temperature rise time: Approx 40 minutes, room temperature -> 1150?
• Control system: Program operation (50 patterns, 100 segments)
• Temperature sensor: K class thermocouple
• Heater capacity: 1.2kW
• Furnace body: Ceramic fiber
• Safety device: Overcurrent breaker, Excessive temperature rise setting device, Door opening and closing sensor, Key lock function, Exterior temperature sensitive type cooling fan, Microcomputer abnormality detection device (heater disconnection, Thermocouple disconnection, Memory content abnormality, Excessive temperature rise abnormality, Control substrate abnormality)
• External output: Recorder thermocouple output, Output for automatic gas introduction 1 - 2, Event contact output 1 - 4, Output for deodorizer, During-operation, end, alarm contact output, 3-color patolight output, SD card slot
• Exhaust port diameter: f23.5mm
• Weight: 22kg
• Power: AC220V
• Current capacity*: 12A (*All numerical data are representative values and are not guaranteed values. *Please prepare plenty of current capacity for power equipment. )
• Accessories: Furnace setter plate, Exhaust port plug, Exhaust sleep, AC cord (300-Plus is attached to the body)
• Option (sold separately): Deodorizer (ES71, ES72) Ventilator (VF71, VF72), Gas introduction unit (KDG-300, -1500, -3000, -5000), 3-color patolight, Different system excessive temperature rise sensor, Body fixing fitting unit, Electrical leakage breaker, Platinel thermocouple, wagon (KDW-100, KDW-200), Temperature sensor for recorder output
• *Vacuum gas replacement furnace type is also available. Please contact with us.
• Model number: 300Plus
• Country of origin: Japan
[Global Model]Muffle Furnace 400 x 470 x 450 220V
AS ONE Corporation
• Outer dimension (mm): 400 x 470 x 450
• Inner furnace dimension (mm): 160 x 245 x 130
• Capacity (L): 5.1
• Operating temperature range: 100? - 1150? (0.5? unit)
• Temperature distribution accuracy: +/- 3? at 1000?
• Temperature rise time: Approx 28 minutes, room temperature -> 1150?
• Control system: Program operation (50 patterns, 100 segments)
• Temperature sensor: K class thermocouple
• Heater capacity: 1.8kW
• Furnace body: Ceramic fiber
• Safety device: Overcurrent breaker, Excessive temperature rise setting device, Door opening and closing sensor, Key lock function, Exterior temperature sensitive type cooling fan, Microcomputer abnormality detection device (heater disconnection, Thermocouple disconnection, Memory content abnormality, Excessive temperature rise abnormality, Control substrate abnormality)
• External output: Recorder thermocouple output, Output for automatic gas introduction 1 - 2, Event contact output 1 - 4, Output for deodorizer, During-operation, end, alarm contact output, 3-color patolight output, SD card slot
• Exhaust port diameter: f23.5mm
• Weight: 33kg
• Power: AC220V
• Current capacity*: 9A (*All numerical data are representative values and are not guaranteed values. *AC cord 3m, 5.5SQ, with grounding (with crimp terminal conforming to M5 screw) *Please prepare plenty of current capacity for power equipment. )
• Accessories: Furnace setter plate, Exhaust port plug, Exhaust sleep, AC cord (300-Plus is attached to the body)
• Option (sold separately): Deodorizer (ES71, ES72) Ventilator (VF71, VF72), Gas introduction unit (KDG-300, -1500, -3000, -5000), 3-color patolight, Different system excessive temperature rise sensor, Body fixing fitting unit, Electrical leakage breaker, Platinel thermocouple, wagon (KDW-100, KDW-200), Temperature sensor for recorder output
• *Vacuum gas replacement furnace type is also available. Please contact with us.
• Model number: 500Plus
• Country of origin: Japan
• Inner furnace dimension (mm): 160 x 245 x 130
• Capacity (L): 5.1
• Operating temperature range: 100? - 1150? (0.5? unit)
• Temperature distribution accuracy: +/- 3? at 1000?
• Temperature rise time: Approx 28 minutes, room temperature -> 1150?
• Control system: Program operation (50 patterns, 100 segments)
• Temperature sensor: K class thermocouple
• Heater capacity: 1.8kW
• Furnace body: Ceramic fiber
• Safety device: Overcurrent breaker, Excessive temperature rise setting device, Door opening and closing sensor, Key lock function, Exterior temperature sensitive type cooling fan, Microcomputer abnormality detection device (heater disconnection, Thermocouple disconnection, Memory content abnormality, Excessive temperature rise abnormality, Control substrate abnormality)
• External output: Recorder thermocouple output, Output for automatic gas introduction 1 - 2, Event contact output 1 - 4, Output for deodorizer, During-operation, end, alarm contact output, 3-color patolight output, SD card slot
• Exhaust port diameter: f23.5mm
• Weight: 33kg
• Power: AC220V
• Current capacity*: 9A (*All numerical data are representative values and are not guaranteed values. *AC cord 3m, 5.5SQ, with grounding (with crimp terminal conforming to M5 screw) *Please prepare plenty of current capacity for power equipment. )
• Accessories: Furnace setter plate, Exhaust port plug, Exhaust sleep, AC cord (300-Plus is attached to the body)
• Option (sold separately): Deodorizer (ES71, ES72) Ventilator (VF71, VF72), Gas introduction unit (KDG-300, -1500, -3000, -5000), 3-color patolight, Different system excessive temperature rise sensor, Body fixing fitting unit, Electrical leakage breaker, Platinel thermocouple, wagon (KDW-100, KDW-200), Temperature sensor for recorder output
• *Vacuum gas replacement furnace type is also available. Please contact with us.
• Model number: 500Plus
• Country of origin: Japan
[Global Model]Muffle Furnace 570 x 575 x 510 220V
AS ONE Corporation
• Outer dimension (mm): 570 x 575 x 510
• Inner furnace dimension (mm): 230 x 305 x 200
• Capacity (L): 14
• Operating temperature range: 100? - 1150? (0.5? unit)
• Temperature distribution accuracy: +/- 3? at 1000?
• Temperature rise time: Approx 25 minutes, room temperature -> 1150?
• Control system: Program operation (50 patterns, 100 segments)
• Temperature sensor: K class thermocouple
• Heater capacity: 3.6kW
• Furnace body: Ceramic fiber
• Safety device: Overcurrent breaker, Excessive temperature rise setting device, Door opening and closing sensor, Key lock function, Exterior temperature sensitive type cooling fan, Microcomputer abnormality detection device (heater disconnection, Thermocouple disconnection, Memory content abnormality, Excessive temperature rise abnormality, Control substrate abnormality)
• External output: Recorder thermocouple output, Output for automatic gas introduction 1 - 2, Event contact output 1 - 4, Output for deodorizer, During-operation, end, alarm contact output, 3-color patolight output, SD card slot
• Exhaust port diameter: f23.5mm
• Weight: 49kg
• Power: AC220V
• Current capacity*: 18A (*All numerical data are representative values and are not guaranteed values. *AC cord 3m, 5.5SQ, with grounding (with crimp terminal conforming to M5 screw) *Please prepare plenty of current capacity for power equipment. )
• Accessories: Furnace setter plate, Exhaust port plug, Exhaust sleep, AC cord (300-Plus is attached to the body)
• Option (sold separately): Deodorizer (ES71, ES72) Ventilator (VF71, VF72), Gas introduction unit (KDG-300, -1500, -3000, -5000), 3-color patolight, Different system excessive temperature rise sensor, Body fixing fitting unit, Electrical leakage breaker, Platinel thermocouple, wagon (KDW-100, KDW-200), Temperature sensor for recorder output
• *Vacuum gas replacement furnace type is also available. Please contact with us.
• Model number: 1500Plus
• Country of origin: Japan
• Inner furnace dimension (mm): 230 x 305 x 200
• Capacity (L): 14
• Operating temperature range: 100? - 1150? (0.5? unit)
• Temperature distribution accuracy: +/- 3? at 1000?
• Temperature rise time: Approx 25 minutes, room temperature -> 1150?
• Control system: Program operation (50 patterns, 100 segments)
• Temperature sensor: K class thermocouple
• Heater capacity: 3.6kW
• Furnace body: Ceramic fiber
• Safety device: Overcurrent breaker, Excessive temperature rise setting device, Door opening and closing sensor, Key lock function, Exterior temperature sensitive type cooling fan, Microcomputer abnormality detection device (heater disconnection, Thermocouple disconnection, Memory content abnormality, Excessive temperature rise abnormality, Control substrate abnormality)
• External output: Recorder thermocouple output, Output for automatic gas introduction 1 - 2, Event contact output 1 - 4, Output for deodorizer, During-operation, end, alarm contact output, 3-color patolight output, SD card slot
• Exhaust port diameter: f23.5mm
• Weight: 49kg
• Power: AC220V
• Current capacity*: 18A (*All numerical data are representative values and are not guaranteed values. *AC cord 3m, 5.5SQ, with grounding (with crimp terminal conforming to M5 screw) *Please prepare plenty of current capacity for power equipment. )
• Accessories: Furnace setter plate, Exhaust port plug, Exhaust sleep, AC cord (300-Plus is attached to the body)
• Option (sold separately): Deodorizer (ES71, ES72) Ventilator (VF71, VF72), Gas introduction unit (KDG-300, -1500, -3000, -5000), 3-color patolight, Different system excessive temperature rise sensor, Body fixing fitting unit, Electrical leakage breaker, Platinel thermocouple, wagon (KDW-100, KDW-200), Temperature sensor for recorder output
• *Vacuum gas replacement furnace type is also available. Please contact with us.
• Model number: 1500Plus
• Country of origin: Japan
[Global Model]Oil Rotary Vacuum Pump 165.5 x 395 x 222.7mm
AS ONE Corporation
• Model number: GLD-051
• Exhaust speed (50/60Hz) (L/min): 50/60
• Achieving pressure (Pa): Gas ballast close 6.7 x 10^-2, Pa gas ballast open 6.7Pa
• Oil used: SMR-100 (included)
• Oil volume: 500 - 800mL
• Power supply:1f220-230V
• Super deluxe type
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
• Exhaust speed (50/60Hz) (L/min): 50/60
• Achieving pressure (Pa): Gas ballast close 6.7 x 10^-2, Pa gas ballast open 6.7Pa
• Oil used: SMR-100 (included)
• Oil volume: 500 - 800mL
• Power supply:1f220-230V
• Super deluxe type
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
[Global Model]Oil Rotary Vacuum Pump Super Deluxe Type
AS ONE Corporation
• Model number: GLD-137CC
• Exhaust speed (50/60Hz) (L/min): 135/162
• Ultimate pressure (Pa): Gas ballast close 6.7 x 10^-1Pa gas ballast open 6.7Pa
• Oil used: SMR-100 (included)
• Oil volume: 1000mL
• Power supply: 1f200-240V
• Weight: 29kg
• Intake tube: KF-25mm
• Size: 170 x 487.5 x 249.5mm
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
• Exhaust speed (50/60Hz) (L/min): 135/162
• Ultimate pressure (Pa): Gas ballast close 6.7 x 10^-1Pa gas ballast open 6.7Pa
• Oil used: SMR-100 (included)
• Oil volume: 1000mL
• Power supply: 1f200-240V
• Weight: 29kg
• Intake tube: KF-25mm
• Size: 170 x 487.5 x 249.5mm
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
[Global Model]Oil Rotary Vacuum Pump Super Deluxe Type
AS ONE Corporation
• Model number: GLD-202BB
• Exhaust speed (50/60Hz) (L/min): 200/240
• Ultimate pressure (Pa): Gas ballast close 6.7 x 10^-1Pa gas ballast open 6.7Pa
• Oil used: SMR-100 (included)
• Oil volume: 1100mL
• Power supply: 1f200-240V
• Weight: 31kg
• Intake tube: KF-25mm
• Size: 170 x 515.5 x 249.5mm
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
• Exhaust speed (50/60Hz) (L/min): 200/240
• Ultimate pressure (Pa): Gas ballast close 6.7 x 10^-1Pa gas ballast open 6.7Pa
• Oil used: SMR-100 (included)
• Oil volume: 1100mL
• Power supply: 1f200-240V
• Weight: 31kg
• Intake tube: KF-25mm
• Size: 170 x 515.5 x 249.5mm
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
[Global Model]Oil-Sealed Rotary Vacuum Pump 165.5 x 423 x 222.7mm
AS ONE Corporation
• Model number: GCD-051X
• Size (mm): 165.5 x 419 x 222.7
• Exhaust speed (effective) (L/min): 50/60 (50/60Hz)
• Achieving pressure (Pa): Gas ballast closed 0.67, Gas ballast open 6.7
• Power (V): 1f220-230V
• Oil used: SO-M (included)
• Oil volume: 500 - 800mL
• Weight: 14.1kg
• Corrosion resistant direct connection type
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
• Size (mm): 165.5 x 419 x 222.7
• Exhaust speed (effective) (L/min): 50/60 (50/60Hz)
• Achieving pressure (Pa): Gas ballast closed 0.67, Gas ballast open 6.7
• Power (V): 1f220-230V
• Oil used: SO-M (included)
• Oil volume: 500 - 800mL
• Weight: 14.1kg
• Corrosion resistant direct connection type
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
[Global Model]Oil-Sealed Rotary Vacuum Pump 170 x 493 x 241.1mm
AS ONE Corporation
• Model number: GCD-136X
• Exhaust speed (effective) (L/min): 135/162 (50/60Hz)
• Size (mm): 170 x 493 x 241.1
• Achieving pressure (Pa): Gas ballast closed 0.67, Gas ballast open 6.7
• Power (V): 1f220V
• Oil used: SO-M (included)
• Oil volume: 1000mL
• Weight: 25.4kg
• Corrosion resistant direct connection type
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
• Exhaust speed (effective) (L/min): 135/162 (50/60Hz)
• Size (mm): 170 x 493 x 241.1
• Achieving pressure (Pa): Gas ballast closed 0.67, Gas ballast open 6.7
• Power (V): 1f220V
• Oil used: SO-M (included)
• Oil volume: 1000mL
• Weight: 25.4kg
• Corrosion resistant direct connection type
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
[Global Model]Oil-Sealed Rotary Vacuum Pump 170 x 509.5 x 241.1mm
AS ONE Corporation
• Model number: GCD-201X
• Exhaust speed (effective) (L/min): 200/240 (50/60Hz)
• Size (mm): 170 x 509.5 x 241.1
• Achieving pressure (Pa): Gas ballast closed 0.67, Gas ballast open 6.7
• Power (V): 1f220V
• Oil used: SO-M (included)
• Oil volume: 1100mL
• Weight: 26.6kg
• Corrosion resistant direct connection type
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
• Exhaust speed (effective) (L/min): 200/240 (50/60Hz)
• Size (mm): 170 x 509.5 x 241.1
• Achieving pressure (Pa): Gas ballast closed 0.67, Gas ballast open 6.7
• Power (V): 1f220V
• Oil used: SO-M (included)
• Oil volume: 1100mL
• Weight: 26.6kg
• Corrosion resistant direct connection type
• *Rubber tube adapter and clamp are not included in the package.
• Country of origin: Japan
10L Keg Kit (For 10L Keg) for Glass Contour MINI
AS ONE Corporation
• Model number: Glass Contour MINI-10KE
• Specification: 10L keg kit (for 10L keg)
• Column size: f50 x 395mm
• Gas supply pressure: Adjusted 0.03 - 0.04MPa or less
• Size: 220 x 240 x 600mm
• Weight: About 6.6kg (except for gas connection hose)
• Solvent outlet: Luer lock (male)
• Set content: Body (column 1 set, Including 2 volumes), gas connection hose, for column rinse tube
• *Please prepare high purity argon gas (G3 grade or more), nitrogen gas (99.999%), regulator for gas pressure adjustment , solvent.
• *No water solvent canister can from each reagent manufacturer, Anything else please choose 10L tank.
• *Power is not required, Please prepare 3P100V power for grounding.
• *Requires a separate installation work cost etc.
• Specification: 10L keg kit (for 10L keg)
• Column size: f50 x 395mm
• Gas supply pressure: Adjusted 0.03 - 0.04MPa or less
• Size: 220 x 240 x 600mm
• Weight: About 6.6kg (except for gas connection hose)
• Solvent outlet: Luer lock (male)
• Set content: Body (column 1 set, Including 2 volumes), gas connection hose, for column rinse tube
• *Please prepare high purity argon gas (G3 grade or more), nitrogen gas (99.999%), regulator for gas pressure adjustment , solvent.
• *No water solvent canister can from each reagent manufacturer, Anything else please choose 10L tank.
• *Power is not required, Please prepare 3P100V power for grounding.
• *Requires a separate installation work cost etc.
Accessories for Desiccator Gas Replacement Unit
AS ONE Corporation
• Model number: Gas replacement unit
• Flowmeter: 10L/min
• Regulator Set pressure range: 0.1 - 0.8MPa
• Bracket fitting x 2 pieces (for outer diameter f6mm tube) included
Activated Charcoal for DL1200 for Neutral Gas 16 Pcs
AS ONE Corporation
• Size: f100 x 304mm/piece
• Model number: Replacement activated carbon filter for neutral gas
• Quantity: 1 set (16 pcs)
Activated Charcoal for DL600 for Acid Gas 6 Pcs
AS ONE Corporation
• Size: f100 x 304mm/piece
• Type of activated charcoal: for acid gas
• Adaptive model: DL-06
• Quantity: 1 set (6 pcs)
Activated Charcoal for DL600 for Basic Gas 6 Pcs
AS ONE Corporation
• Size: f100 x 304mm/piece
• Type of activated charcoal: for basic gas
• Adaptive model: DL-06
• Quantity: 1 set (6 pcs)
Activated Charcoal for DL600 for Neutral Gas 6 Pcs
AS ONE Corporation
• Size: f100 x 304mm/piece
• Type of activated charcoal: for neutral gas
• Adaptive model: DL-06
• Quantity: 1 set (6 pcs)
Activated Charcoal for DL900 for Acid Gas Pcs
AS ONE Corporation
• Size: f100 x 304mm/piece
• Model number: Replacement activated carbon filter for acid gas (10 pieces)
• Dry
Activated Charcoal for DL900 for Basic Gas Pcs
AS ONE Corporation
• Size: f100 x 304mm/piece
• Model number: Replacement activated carbon filter for basic gas (10 pieces)
• Dry
Activated Charcoal for DL900 for Neutral Gas Pcs
AS ONE Corporation
• Size: f100 x 304mm/piece
• Model number: Replacement activated carbon filter for neutral gas (10 pieces)
• Dry
Airtight Glove BOX (With Chamber Pressure Control) 1090 x 535 x 500
AS ONE Corporation
• Model number: Air tight 800+PCRM-01
• Size (mm): 1090 x 535 x 500
• Minimum operation differential pressure/Minimum display units pressure: 0.05kPa/0.01kPa
• Material: Body/Transparent PMMA (acrylic resin), Valve, Vacuum gauge mounting portion/PC (polycarbonate), Hinge Base/PMMA (acrylic)
• External connection: Air supply port (negative pressure side)/Outer diameter f8mm tube (one touch method), Gas (air also available) supply port (positive pressure side)/Outer diameter f8mm tube (one touch method), Exhaust port/Outer diameter f10mm tube (one touch method)
• Supplied air pressure: 0.4 - 0.6MPa (consumption: 80L/min(ANR))
• Supply gas pressure: 0.6MPa or less
• Power supply: AC100V 50/60Hz
• Weight: 37kg
• Accessories: Valve x 1 piece (outer diameter f14mm), Large Gloves for Glove box x 1 pair
• By connecting to external gas supply source, difference between outer air pressure(outside box) and pressure in glove box is maintained smaller than specified small pressure difference(-0.5kPa~-0.01kPa or 0.01kPa~0.5kPa) automatically and displayed in digital form.
• When pressure difference is out of specified range, alarm will be displayed.
Airtight Glove Box (With Internal Pressure Control) With Outlet
AS ONE Corporation
• Size (mm): 485 x 890 x 450
• Minimum differential pressure/Minimum display unit pressure: 0.01 kPa/0.05 kPa
• Material : Main unit/Transparent PMMA (Acrylic Plastic) , Valve and Vacuum Meter Mounting Unit/Polycarbonate , Hinge Base/PMMA (acrylic)
• External Connections
• *Air supply port (negative pressure side): outer diameter f8 mm tube (one-touch)
• *Gas (You can also use air.) Supply port (positive pressure side): outer diameter f8 mm tube (one-touch)
• *Exhaust port: outer diameter f10 mm tube (one-touch)
• Supply Air Pressure: 0.4 to 0.6 MPa (Consumption: 80 L/min (ANR))
• Supply gas pressure: 0.6 MPa or less
• Power supply: AC100V 50/60 Hz
• Outlet specs: 2 AC100V outlets
• Weight: 28 kg
• Accessory: Valve x 1 piece (outer diameter f14 mm), glove large x 1 pair for glove box
